Purlin vs. Purlinless Wall Systems: How to Choose

In industrial construction, the purlin system is the traditional standard for wall systems. Purlins act as vital structural components, transferring loads between the wall panels and the main frame. However, with advancements in high-performance rock wool cores and optimized joint designs, the purlinless system has emerged as a mature, reliable, and increasingly popular alternative.

But which one is right for your project? We break it down into three critical factors: Protection, Efficiency, and Aesthetics.

1. Protection: Wind Resistance & Waterproofing

How do these systems hold up against the elements?

• Purlinless System: The wall panels are directly connected to the structural columns using through-bolts, creating excellent structural integrity. With fewer joints and fasteners, the risk of leakage is significantly reduced.

• Note: Due to the lack of intermediate support, high-rigidity cores (like structural rock wool) are required to prevent bending in long panels.

• Purlin System: Panels are attached to the purlins via hidden fasteners in the joints. The wind resistance depends on the interlocking strength of the joints.

• Pro Tip: Systems using staggered double-support joints and 3D reinforcement gaskets can greatly enhance weatherproofing.

The Suggestions: For rainy or typhoon-prone areas with column spacing ≤ 8m and few windows, purlinless is a strong choice. For projects with large column spacing or dense window placement, the purlin system offers superior flexibility.

2. Efficiency: Construction Speed & Cost

Time is money in industrial projects.

• Purlinless System: By eliminating the need for purlin installation and internal lining sheets, this prefabricated approach drastically shortens the construction cycle and reduces labor costs.
• Purlin System: Requires step-by-step installation of individual purlins, which increases on-site workload and extends the project timeline.

The Suggestions: Choose purlinless for tight deadlines and simplified wall designs. Opt for purlin systems if your design requires high flexibility for window and door openings.

3. Aesthetics: Interior & Exterior Finish

The visual impact matters for modern industrial facilities.

• Purlinless System: The interior side is completely flat and clean with no exposed purlins, making it ideal for high-end manufacturing or clean-room environments.
• Purlin System: While purlins are visible internally (unless an inner lining is added), the exterior allows for diverse facade designs through varying panel widths and installation directions.

The Suggestions: Purlinless wins on interior neatness. Purlin systems win on exterior architectural variety.

Key takeaway: Purlin systems offer design flexibility and are suitable for wide column spacings (≤12 meters); purlin-free systems provide an aesthetically pleasing interior and efficient construction, making them ideal for projects with few windows and tight schedules. Both systems have their own advantages, so it is recommended to make a comprehensive assessment based on factors such as wind pressure, column spacing, and window placement.

Conclusion: The Quick Cheat Sheet

Final Recommendation: Selecting the right system depends on your project’s specific wind pressure requirements, column spacing, and architectural goals. At Glostar, we provide mature solutions for both, ensuring your building is not only functional but also enduringly beautiful.
